Lab Tour
Major Experimental Facilities
SLA Printer
It is used for 3D printing transparent objects which can be used for flow visualization. This printer uses light-reactive thermoset materials called “resin”. When SLA resins are exposed to certain wavelengths of light, short molecular chains join together, polymerizing monomers and oligomers into solidified rigid geometries.
Specifications
FormLabs 3B+, USA corp, 45µm native resolution and 25-100µm cure depth
Laser Beam Expander
Use to enhance the laser beam diameter for adequate flow visualization. Currently, 3X and 5X Laser beam expanders are available.
Specifications
Edmund optics
FASTEC High Speed Camera
Fastec IL5 high-speed camera is compact yet versatile recording systems used for lab research, where speed and accuracy are needed. Common applications include flow visualization in transparent 3D printed human organ phantoms.
Specifications
Resolution: 3.375µm/pixel 1920 x 1080 (HD: 1080p) Frame rate : 634 fps
Baumer High Speed Camera
These cameras are known for its High frame rates, exceptional image quality and ease of integration. This is a model with Precision Time Protocol (PTP) for precise time synchronization in Ethernet networks, with polarization sensor for the complete detection of the linear polarization state of surfaces, as well as global shutter, rolling shutter, or global reset shutter. Currently being used for flow visualization in human body phantoms.
Specifications
Resolution: 800 × 620 pixel, max. 1550 fps
High-Speed Camera Lens
Two types of lenses, namely telecentric and wide angle are currently employed for high speed flow visualization in laboratory.
Specifications
Telecentric and Wide angle lens (Make: Myutron)
Data Acquisition System
Data Acquisition systems are needed to actuate the high speed camera, record the flow visualization data and further store the data obtained while experimentation.
Specifications
USB based Data acquisition system Make: Aimil Ltd.
Model: Aimil_USB_DAQ_3.0USB based Data acquisition system Make: Thermo Fisher Scientific.
Model: DT82E
Syringe Pump
Syringe pump, also known as a syringe driver, is an infusion pump that helps deliver an accurate amount of fluids, whether nutrients or medications, into the patient's body in a controlled manner. In our lab it is usually used for delivering patient specific flow rates for in vitro blood flow experiments.
Specifications
NiscomMed,SP-04
Magnetic Strrier with Hot Plate
A magnetic stirrer with a hot plate is a device that combines heating and stirring capabilities. It features a flat hot plate for heating liquids and a motorized magnet underneath to stir the contents using a magnetic stir bar. In our lab it is used for preparing Newtonian and non Newtonian blood mimicking fluids.
Specifications
LABWAN,LW-28
Digital ultrasonic Bath Sonicator
An ultrasonic bath sonicator is a device that uses high-frequency sound waves to agitate in a liquid medium. It consists of a tank filled with solvent where samples are immersed, and features controls for adjusting parameters like sonication time and power. Used for tasks like cell disruption and sample homogenization, it offers enhanced mixing.
Specifications
Labtronics, LT350B
Cool White Light Source
Cool white light sources are often used in PIV (Particle Image Velocimetry) because of their specific optical and performance characteristics that suit the high-precision requirements of this technique. Particle imaging velocimetry (PIV) uses light scattering by small seed particles to track their motion
Specifications
Shalya Endolux, ELE24H02C
Infusion pump
It is a full-featured syringe infusion pump, meticulously engineered to provide a comprehensive solution for both critical care and general infusion applications. It offers precise and reliable drug delivery, making it ideal for use in drug delivery experiments. The device is equipped with advanced features, such as occlusion detection, anti-bolus mechanisms.
Specifications
Infusion pump, BPL ACURA V1, KMTA4H5965
Computational Facilities
Tyron Workstation
Specifications
2 X Intel® Xeon® Gold 5218 R Processor @2.99 GHz
192 GB DDR4-2933 RAM with 48 cores and 2TB storage
HP Z6 Workstation
Specifications
2 X Intel® Xeon® Gold 5218 R Processor @2.99 GHz
128 GB DDR4-2933 RAM with 40 cores and 1TB storage
Asrock Workstation
Specifications
Intel® Xeon® W7-3445 Processor @4.6 GHz
128 GB DDR5-4800 RAM with 40 cores and 1TB storage
AMD-Ryzen Workstation
Specifications
AMD Ryzen 9 5900X Processor @3.70 GHz
128 GB RAM with 12 cores and 1TB storage
